Ewellix wide profile rail guide range supports nearly any solution for linear or cartesian robots.
SLIDEKIT 2.0 0S
Benefits
- Enhanced return on investment for the complete installation
- SLIDEKIT2.0 0S S00 for small & medium-sized cobots up to 50 kg
- SLIDEKIT2.0 0S S20 for large cobot-size cobots up to 75 kg
- No hardware/software development needed
- Direct positioning access within the robot controller environment
- Fast positioning to increase productivity and save costs
- Compatible with VISUAL COMPONENT software
- Optional top plate for robot mounting on SLIDEKIT available upon request
Features
- Communication protocol Ethernet TCP/IP covering the majority of robot controllers and PLCs
- Ready-to-use complete system solution
- Large library of script commands making integration of SLIDEKIT movement simple and fast
- High level of positioning precision and repeatability
- Very low noise in operation
Many applications - such as finishing, welding, and parts inspection - require covering long distances. These repetitive, manual tasks are time-consuming and offer low added value for operators.
Integrating a linear module as a dynamic base extends the robot’s operating range, increasing productivity and output quality. The SLIDEKIT 2.0 enables fast installation with standardized mechanical, electrical, and software interfaces that is compatible with any robot.
Thanks to the Ethernet TCP/IP communication protocol included in the SLIDEKIT control box, which is suitable for most robot controllers and PLCs, the system ensures seamless integration.
The optional top plate simplifies integration of the SLIDEKIT with your robot, making the system ready for immediate operation and easy programming.
Technical Data
Overview
| SLIDEKIT-0S BE S00 | SLIDEKIT-0S PE S00 | SLIDEKIT-0S PE S20 | |
|---|---|---|---|
| Robot compatibility | small & medium size cobot up to 50 kg | small & medium size cobot up to 50 kg | large size cobot up to 75 kg |
| Dynamic payload (N) | 10 900 | 10 900 | 16 000 |
| Max stroke (mm) | 1 800 | 1 800 | 3 000 |
| Operating temperature | 0 to +50 °C | 0 to +50 °C | 0 to +50 °C |
| Drive | Ball screws | Belt drive | Belt drive |
| Mounting | Floor mount Ceiling mount Wall mount (lateral) |
Floor mount Ceiling mount |
Floor mount |
| Repeatability (mm) | ± 0,01 | ± 0,08 | ± 0,08 |
| Max. linear speed (mm/s) | 1 000 | 1 000 | 300 |
| Duty cycle (%) | 100 | 100 | 100 |
Publications
IL-07041-EN-June-2025 - Linear axis for any collaborative robots SLIDEKIT 2.0 0S
TC-08062-EN-June-2025 - SLIDEKIT-0S operating manual
EL-03012/2-EN-November 2024 - Linear technology for flexible assembly lines
EL-03018/1-EN -February 2023 - 7th axis solutions to boost your robot s capabilities
EL-03023/1-EN-November 2024 - Solution for food and beverage
